Constant Pressure Frequency Conversion Cold And Hot Water Self-priming Pump BPWZB70-800/BPWZB90-1500

Production Instruction:
WZB automatic Cold and Hot Water Vortex Self-priming Pump Series. The motor is an asynchronous motor, the impeller structure of the electric pump is a whirlpool type, which has the characteristics of small flow, high lift and good self-priming. The electric pump configuration control system realizes the automatic operation of the electric pump according to the change of water pressure or water flow, that is, to open the valve electric pump automatically, to close the valve electric pump automatically, and to shut down the electric pump automatically without the need to turn off the power supply manually. This series has the function of stabilizing water supply, small volume, light weight, compact structure, simple and convenient installation. It is an ideal household electric pump with high efficiency, energy saving and safety.

Working Conditions:
The maximum fluid temperature is <80 °C
Maximum acceptable pressure is 10bar
Maximum ambient temperature is 40 °C
