Application For pumping clean water with sand content less than 150g/m³
For well pumping, river pumping, farm irrigation, water supply.
Operating conditions
Water temperature up to 35℃
Ambient temperature permissible up to 40℃
2SDM Minimum internal diameter of well: 2"(50mm)
2.5SDM Minimum internal diameter of well: 2.5"(65mm)
Maximum immersion depth: 80m
Motor
Rewindable motor
Insulation Class B
Protection IP68
NEMA dimension standards
